NewBlue Captivate

Works, untested. NewBlue Captivate is the new name of NewBlue Titler Live (since version 5.7, 2023), so these steps apply to both. Two ways: ScoreSight pushes the values to Captivate (push), or Captivate reads them from ScoreSight (pull). In both, name the graphic’s text variables exactly like the ScoreSight fields (Home Score, Away Score, Time…).

Video: ScoreSight with NewBlue Captivate (an earlier version of ScoreSight)

The video shows an earlier version of ScoreSight; the steps below are for the current one.

On this page
  1. Push: ScoreSight sends the values
  2. Pull: Captivate reads ScoreSight
  3. Notes
  4. Vendor documentation

Push: ScoreSight sends the values

For Captivate Broadcast. Whether the Sport edition accepts it is unverified.

  1. In Captivate’s Designer, make the graphic’s text layers variables named like the ScoreSight fields, and keep the changes. For a ready-made title, list its variables with curl --data "{\"command\":\"readTitle\",\"parameters\":{\"title\":\"<Title Name>\"}}" -H "Content-Type: application/json" http://<captivate-ip>:9022/api/ and rename the ScoreSight fields to match (for example Away Score to Visitor Score).
  2. In ScoreSight, select HTTP API in the Outputs list (Outbound HTTP API) and set:
    • URL: http://<captivate-ip>:9022/api/action/still/title/<Title%20Name> (the title’s name, percent-encoded; update instead of still animates the change; /input/<input name> instead of /title/... targets every title on an input);
    • method POST, Encode JSON (Simple key-value);
    • Send: tick Only changes, so Captivate gets a request only when a value changed (leave Fields on All in one request).
  3. Tick Send out API requests to external services. and allow TCP port 9022 through the Captivate computer’s firewall.

To test without ScoreSight:

curl -H "Content-Type: application/json" --data "{\"Home Score\":\"21\"}" "http://<captivate-ip>:9022/api/action/still/title/<Title%20Name>"

Pull: Captivate reads ScoreSight

For Captivate Sport and Broadcast.

  1. Select the graphic, then Select a data controller > General > JSON > New Input.
  2. Enter http://<scoresight-ip>:18099/json?pivot&all (the HTTP server). Or use the XML reader with http://<scoresight-ip>:18099/xml?pivot&all, whose element names have no spaces: HomeScore.
  3. Open Link Data and drag each variable onto its text object.

&all keeps every field in the data, with its last good value, so a variable never goes blank while a reading is rejected.

Notes

  • Captivate’s documentation mentions network and FTP addresses for the readers; whether it accepts a plain http:// address, and how often it reads it, isn’t documented.
  • Captivate’s API needs nothing to be turned on, but port 9022 must be free when Captivate starts. NewBlue’s comparison chart lists the API under Broadcast only.
  • Captivate also takes the same JSON messages over TCP (port 9025) and UDP (port 9026), which the TCP / UDP output could send with a Custom template. The HTTP route above is simpler.
